Project Description
Bitumen 80/100 would be one of the main products of PETRO-ACC with the highest quality and standard items that would be necessary for Bitumen 80/100 product.
So follow of this item we are honored that can supply all of our clients with high quality and best packing conditions such as new steel drums and Jumbo bags.
| Name | Bitumen 80/100 |
| Manufacturer | PETRO-ACC |
| Made By | Aras Petrochemical Company |
| Product Grade | 80/100 |
BITUMEN 80/100 MSDS
Table scrolling horizontally
| Material Safety Data Sheet of Bitumen 80/100 | |
| Product Name | Bitumen |
| Catalog Codes | APC210 |
| CAS# | 8052-42-4 |
| Color: | Dark Brown |
| Odor: | Asphaltic |
| Odor Threshold -ppm: | NA |
| pH: | NA |
| Boiling point °C: | NA |
| Hazards Identification |
|
| First Aid Measures |
|
| Fire-Fighting Measures |
|
Table scrolling horizontally
BITUMEN 80/100 FEATURES
Bitumen 80/100 technical details
The quality of this type of bitumen shows its characteristics and specifications. In addition to penetration testing, there are tests used to determine bitumen grade, including viscosity, softening point, shape, heat loss, and flash point.
Some of these are for bitumen 80/100 suppliers and customers. They should be more important. These are the softening point and the Flash point.
According to ASTM D36 method, the softening point of this grade of bitumen is between 45 and 52 ° C and the flash point of this grade of bitumen is 225 ° C.
BITUMEN 80/100 APPLICATIONS
This type of bitumen is used for road construction projects in temperate regions and It can also be used to produce some of the basic layers of asphalt and insulation.
BITUMEN 80/100 FORMULATION
This type of Bitumen is known by some formula according to application in industries such as:
Elementally, it contains 88% carbon and around 9% hydrogen, and other chemical contents are up to 4% sulfur, 1% nitrogen, 1% oxygen, and 2000ppm metals.
Bitumen Products are composed mainly of highly condensed polycyclic aromatic hydrocarbons.
BITUMEN 80/100 PACKING
Packing of our bitumen would be 180 kg new steel drums and 1000 kg Jumbo bags.
BITUMEN 80/100 SPECIFICATION
| SPECIFICATION | TEST METHOD | A.S.T.M. |
| SPECIFIC GRAVITY AT 25/25 DEG C | 1.01/1.05 | D.70 |
| PENETRATION AT 25 DEG C | 80/100 | D.5 |
| SOFTENING POINT DEG C | 45/52 | D.36 |
| DUCTILITY AT 25 DEG C CMS | 100 MIN | D.113 |
| LOSS ON HEATING PCT WT | 0.5 MAX | D.6 |
| DROP-IN PENETRATION AFTER HEATING PCT | 20 MAX | D.5 |
| FLASH POINT DEG C | 225 MIN | D.92 |
| SOLUBILITY IN CS2 PCT WT | 99.5 MIN | D.4 |
| ORGANIC MATTER INSOLUBLE IN CS2 PCT WT | 0.2 MAX | D.4 |
| SPOT TEST | NEGATIVE | *A.A.S.H.O T102-42 |
